The UDO2000 series digital phosphor oscilloscope is a multifunctional and high-performance oscilloscope based on UDM-T's original Ultra Phosphor technology. It realizes the combination of ease of use, excellent technical indicators and many functional features. It can help users complete the measurement work faster. Fast Acquire technology can accurately capture abnormal events such as video, jitter, noise and low wave signals.
The UDO2102 Digital Storage Oscilloscope is a powerful and reliable test instrument designed for engineers, technicians, laboratories, and electronics enthusiasts. With 100MHz bandwidth and dual-channel input, this oscilloscope delivers precise waveform analysis and accurate signal measurement for a wide range of electronic applications.
Built with advanced digital signal processing technology, the UDO2102 offers high sampling performance, deep memory depth, and fast waveform capture, enabling users to analyze complex electronic signals efficiently. The oscilloscope features a high-resolution color display, providing clear visualization of waveforms for easy troubleshooting and debugging.
The UDO2102 supports multiple trigger modes, automatic measurements, and mathematical functions, making it ideal for analyzing signal behavior in embedded systems, communication devices, power electronics, and industrial equipment. Its user-friendly interface and intuitive controls allow both professionals and students to operate the device with ease.
With modern connectivity options such as USB interface for data storage and PC connectivity, users can easily save waveform data, screenshots, and measurement results for further analysis and documentation.
The UDO2102 Digital Oscilloscope is widely used in electronics repair, R&D laboratories, education institutes, automotive electronics testing, and industrial maintenance, offering reliable performance and professional-grade measurement capabilities.
| Modal Name | Download |
|---|---|
| UDO2102 Datasheet |
|
The 8-inch touch screen design supports a variety of gesture operations, such as click, slide, zoom, edit, drag, etc. Make the measurement action smoother and more convenient, and users can master it more quickly. At the same time, the traditional button and knob operation is still retained, and the interactive experience is optimized to the greatest extent.
Automatic parameter measurement up to 36 kinds. Provides a variety of automatic measurement parameters while you measure waveforms, greatly improving your measurement efficiency.
XY mode cursor measurement can quickly measure the phase difference between two signals.
Using innovative digital signal parallel processing technology, it can reach an ultra-high capture rate of 200,000wfms/s in normal sampling and 1,000,000 wfms/s in Fast Acquire mode. Efficient capture of occasional signals.
The oscilloscope can maintain a high sampling rate in a wider time base range, while taking into account the overall and details of the waveform, greatly improving the capture rate of abnormal waveforms.
With a wealth of advanced trigger and bus trigger functions, it can help users accurately and quickly capture and display the signal of interest.
The decoding speed is greatly improved. The full-memory hardware decoding under the deep storage of 70Mpts, the decoding time is increased from more than ten seconds to milliseconds, which realizes real-time decoding and greatly improves the user's problem diagnosis efficiency.The recorded waveform also supports full-memory hardware real-time decoding.
The area trigger can be used in combination with the existing basic trigger, advanced trigger and protocol trigger to complete the capture of various occasional and complex characteristic signals.
With a built-in dual-channel 50MHz arbitrary waveform generator, the device seamlessly combines an oscilloscope, logic analyzer, and signal source into a unified tool, enhancing your testing experience with greater efficiency.
Can be used for loop analysis. It is a critical measurement often used to characterize the frequency response (gain, phase, and frequency) of today's various electronic designs, including passive filters, amplifier circuits, and negative feedback networks for switch-mode power supplies.
Can be used for parallel bus, protocol decoding and timing measurements.
Provides two 8-channel splitters and simplifies connection to the device under test. When connecting with square pins, UD-M15 can be directly connected with 8X2 square pin headers with pins of 2.54mm. The UD-M15 offers excellent electrical characteristics with an input impedance of 101k? and a capacitive load of only 9.0pF.
